Item
Specification
Condition
Nominal Capacity
15Ah
25±2ºC, 0.5C/0.5C
Minimum Capacity
14.5Ah
25±2ºC, 0.5C/0.5C
Operating Voltage
1.5~3.95V
/
Nominal Voltage
3.0V
/
AC Internal Resistance
1.5±0.3mΩ
AC 1KHz, 50% SOC, 25±2ºC
Cell Weight
390±10g
Contain package
Energy Density
115Wh/kg
255Wh/L
/
Operating Temperature
Charging Temperature: -10~60ºC
Discharge Temperature: -40~65ºC
No matter what charging and discharging mode the cell is in, once the cell surface temperature exceed this range,
the charging and discharging should be stopped.
Storage Temperature
-40ºC~35ºC:3months
-10ºC~25ºC:6months
/
Cycle life
≥2000cycles
25±2ºC, 0.5C/0.5C, 80%SOH.
Appearance
Without break, scratch, distortion, contamination, leakage and so on.
/
3C
Item
Specifications
Condition
Standard Charging Mode
/
0.5C CC/CV, cut off 3.95V/0.05C
Standard Charging Current
0.5C
/
Max.Continuous Charging Current
20~40ºC
Standard End-of-charge Voltage
3.95V
/
Optimum Charging Temperature Range
15~40ºC
Cell surface temperature
Item
Specifications
Condition
Standard Discharge Mode
/
0.5C CC, cut off 1.50V
Standard Discharge Current
0.5C
/
Max.Continuous Discharge current
5C
15~45ºC
Max.Discharge Pluse Current
10C
15~45ºC, 10S, 50%SOC
End-of-discharge Voltage
1.5V
/
If you want to know more, pls feel free to contact us to get complete specification.
