AC 1KHz, 30% SOC
Standard Deviation≤0.2mΩ
162Wh/kg
396Wh/L
Charging Temperature: 0~60ºC
Discharge Temperature: --30~60ºC
-20ºC~45ºC:3months
-10ºC~25ºC:6months
Standard cycle: ≥2500cycles 25±2ºC, 0.5C/0.5C, 80%SOH.
Fast charge cycle: ≥3000cycles 25±2ºC, fast charge/1C discharge, 70%SOH
Project
Specification
Condition
Nominal Capacity
15Ah
25±2ºC, 0.5C/0.5C
Minimum Capacity
14.5Ah
25±2ºC, 0.5C/0.5C
Operating Voltage
2.0~3.6V
/
Nominal Voltage
3.2V
/
AC Internal Resistance
1.0mΩ≤IR≤3.0mΩ
Cell Weight
295±10g
Contain package
Energy Density
/
Operating Temperature
No matter what charging and discharging mode the cell is in, once the cell surface temperature exceed this range, the charging and discharging should be stopped.
Storage Temperature
/
Cycle life
/
Appearance
Without break, scratch, distortion, contamination, leakage and so on.
-10~0ºC: 0.2C; 0～10ºC: 0.33C; 10~20ºC: 0.5C;
20~45ºC: 1C; 45～50ºC: 0.5C; 50~60ºC: 0.2C;
Project
Specifications
Condition
Standard Charging Mode
/
0.5C CC/CV, cut off 3.6V/0.05C
Standard Charging Current
0.5C
/
Max.Continuous Charging Current
/
Standard End-of-charge Voltage
3.6V
/
Max End-of-charge Voltage
3.6V
No matter what charging mode the cell is in, once the cell voltage exceeds this range, the charging should be stopped.
Fast Charge Charging Time
30min
30%~80%SOC, 25ºC
Optimum Charging Temperature Range
15~40ºC
Cell surface temperature
Max.Charging Temperature Range
0~60ºC
No matter what charging mode the cell is in, once the cell surface temperature exceeds this range, the charging should be stopped.
Project
Specifications
Condition
Standard Discharge Mode
/
0.5C CC, cut off 2.0V
Standard Discharge Current
0.5C
/
Max.Continuous Discharge current
2C
15~45ºC
Max.Discharge Pluse Current
6C (10s)
15~45ºC
End-of-discharge Voltage
2.0V
/
Max.Discharge Temperature Ranges
-30~60ºC
No matter what discharge mode the cell is in, once the cell surface temperature exceeds this range, the discharge should be stopped.
If you want to know more, pls feel free to contact us to get complete specification.
