Item
Specifications
Diameter (With PVC): 21.65±0.2mm;
Height (With PVC): 70.85±0.2mm.
Charge: 0~45C
Discharge: -20~60˚C
Min 1 month: -5~35ºC
Min 6 month: 0~35ºC
Typical Capacity
5000mAh @0.2C, 25˚C
Minimum Capacity
4800mAh @1C, 25˚C
Nominal Voltage
3.6V
Internal Impedance
≤20mΩ
Discharge Limited Voltage
2.5V
Charging limited Voltage
4.2V
Standard Charging
0.5C
Maximum Charging
3C (not for cycle life)
Standard Discharging
1C
Quick Discharging
3C (not for cycle life)
Max Discharge Current
5C (≤3S)
Weight
70.0±4.0g
Dimension
Operating Temperature (Ambient)
Storage Temperature
Pls feel free to contact us to get this cell complete specification.
