Item

Condition

Specification

Remark

Nominal capacity

1Cdischarge capacity

6.0Ah

AC IR

AtAC 1000Hz

≤8mΩ

DC IR

DC IR=(V1-V2)/1C

≤16mΩ

Nominal voltage

3.2V

Size

Height: 70.5+0.4/-0.3mm

Diameter: 32.2±0.3mm

Weight

145±5g

Cut-off charge voltage

CC

3.65V

Cut-off charge current

CV

≤0.3A

Charging method

Standard charge

≤1C at CC/CV

Cut-off dicharge voltage

CC

2.0V

Max continuous discharge current

18A

≤20min

Max pulse discharge current

60A

3s

Cycle life

1C/100%DOD

2200times

Operating temperature range

Suggested charging temperature

<0ºC

Prohibitcharging

0~10ºC

≤0.2C

10~15ºC

≤0.5C

15~45ºC

≤1C

45~60ºC

≤0.5C

Discharging temperature

-20~60ºC

1C

Storage temperature

-20~45ºC

Appearance

Without break, scratch, distortion, contamination, leakage and so on
